What is SA32E – Standalone Card Access Control System
The SA32E – Standalone Card Access Control System is a compact and cost-effective electronic security device from ESSL that controls access to doors using RFID cards, PIN codes, or a combination of both. It is specifically designed for small to medium-sized businesses, residential complexes, offices, and similar environments where a simple yet secure access control solution is needed.
Why Choose the SA32E – Standalone Card Access Control System?
1. All-in-One Security Without Software Dependency
The SA32E doesn’t require any external software to function. It’s a plug-and-play system, allowing administrators to register cards, set PINs, and manage users directly from the device itself.
- Small businesses without IT support
- Quick deployments for construction sites
- Residential complexes with budget constraints
2. Multi-Mode Access Options
Users can access using:
- RFID Card only (EM ID card)
- PIN code only
- Card + PIN for dual-layer security
3. Impressive User Capacity
Up to 1000 cardholders can be registered, making it ideal for medium-scale setups. With Wiegand 26 input/output support, you can scale it by integrating it with a broader access control system.
4. Simple Yet Secure Installation
Thanks to its compact dimensions (121×78×23mm) and DC 12V operating voltage, the device installs quickly on any wall or surface. It supports:
- One Relay Output: For door strike or electromagnetic lock
- One PUSH (low) Output: Integration with alarm or access systems
- One Door Button Input: For manual unlocking
- One Doorbell Port
No need for complex wiring or configuration tools.
Technical Specifications at a Glance
| Specification | Value |
|---|---|
| Operating Voltage | DC 12V ±10% |
| Operating Current | < 100mA |
| Dimensions | 121×78×23mm |
| Weight | 110g |
| Temperature | 0°C – 60°C |
| Humidity | 20% – 80% |
| User Capacity | 1000 users |
| Card Type | EM (ID) card (IC optional) |
| Card Reading Distance | 1 – 15cm |
| Installation | Indoor, wall mount |
| Wiegand Support | 26-bit input/output |
Use Cases of SA32E – Standalone Card Access Control
1. Offices and Co-Working Spaces
- Limit access to authorized employees only
- Set card + PIN for executive zones
2. Retail Stores and Showrooms
- Secure staff-only areas
- Deter shoplifting by restricting backroom entry
3. Residential and Apartment Buildings
- Grant tenants easy access via cards
- Prevent unauthorized visitors from accessing sensitive areas
4. Schools, Clinics, and Labs
- Ensure that only faculty or medical personnel access specific rooms
- No need for cumbersome keys
SA32E vs. Traditional Lock-and-Key Security
| Feature | Traditional Locks | SA32E Standalone |
|---|---|---|
| Security | Vulnerable to key theft or duplication | PIN + RFID options |
| Scalability | Replacing keys is tedious | Add/remove users instantly |
| Access Logging | Not possible | (Limited in standalone mode) |
| Ease of Use | Manual, physical | Contactless card or PIN |
| Integration | None | Wiegand-enabled for future growth |
Installation and Setup – No IT Team Needed
- Mount the Device on a wall or entrance door.
- Connect the Relay Output to your door lock.
- Power It On using a 12V power supply.
- Enroll Users directly using the keypad (Add/Delete cards and PINs).
- Configure Access Mode (Card, PIN, or Card + PIN).
Need help? We’ve covered an easy DIY guide on our installation page.
Integration Possibilities: Future-Proof Your Access
Thanks to the Wiegand 26-bit input and output, the SA32E can easily communicate with other access control devices, including:
- Biometric scanners
- Exit readers
- Control panels
You can start with a simple SA32E setup today and integrate it into a larger, centralized access control network tomorrow.
For technical documentation on Wiegand communication, check out this helpful article by HID Global.
Pros and Cons of SA32E – An Honest Look
Pros
- Affordable
- No software or server dependency
- Multiple access modes
- Easy to install and manage
- Wiegand support for future expansion
Cons
- No mobile app support
- No network connectivity for remote monitoring
- Indoor use only (not weatherproof)
If you don’t need cloud or remote access, the SA32E remains unbeatable at this price point.
Where to Buy SA32E – Standalone Card Access Control in Chennai
Looking to secure your premises in Chennai or nearby cities?
We offer fast installation, expert consultation, and competitive pricing for ESSL access control systems. Visit our product page for SA32E Card Access Control System in Chennai or contact us today for a demo.
Conclusion:
If you’re looking for a simple, secure, and affordable access control system, the SA32E – Standalone Card Access Control checks all the boxes. It combines ease of use, high user capacity, multiple access methods, and expansion options into one powerful device.
- Explore top-rated models like the ATSS SA32E and choose the best for your facility today. ATSS – Call:91500 12345.
