ET-2000 One-Way Bridge Tripod Turnstile
The ET-2000 One-Way Bridge Tripod Turnstile ESSL is a high-quality, durable, and efficient turnstile that is ideal for use in a variety of applications, including:
- Access control for pedestrian traffic in high-security areas
- Managing crowds and preventing unauthorized access
- Integrating with access control systems
FEATURES
- Passage width : 550mm
- Throughput rate : 35 p/m
- Power supply : 100 ~ 240V
- Operational voltage : 24V
- Max tolerance of Arms : 80 Kg
- Angle per rotation : 120 °
- Operation Type : One-way – Bidirectional
- Input control signal : Dry contact
- Max Power Consumption : 30 W
- Frequency : 50 ~ 60hz
- Protection level : IP44
- Working temperature : -25°C ~ +70°C
- Electro – magnetic drive : DC
- Dimension Excluding Bar : 1200x280x980 mm
- Net weight including bar : 52kg
- Opening Duration : 5s – 60s
- MCBF : 5 Million
PRIMARY CONTROLLER (INBUILT)
- CPU : 32 bit Microprocessor
- Opening Signal Input : yes
- Emergency Switch Input : yes
- Direction Indicator Output : yes
- Passing Indicator Output : Yes
- Drop Arm Electromagnet Output : Yes
- Material Housing : SUS 304
- Operating Mode: Single way bi directional
- Primary controller: Semi-automatic mode
SECONDARY CONTROLLER
- Users : 30000 (RFID)
- Fingerprint : 3000
- Transaction storage : 100000
- Integrated Controller : inbio-260
- Relay : 12 V relay for lock
- Support Fire Alarm : Yes
READER
- RFID : Yes | Fingerprint : Yes
- Protocol : RS485 / Mifare/Proxy (Optional) : Yes
The ET-2000 is made of stainless steel and is designed to withstand heavy use. It has a passage width of 550mm and a throughput rate of 35 p/m. The arms are spring-loaded and can withstand a maximum of 80 kg of pressure. The turnstile can be operated in a variety of modes, including:
- Manual mode: The arms are unlocked and can be rotated freely.
- Automatic mode: The arms are locked and can only be rotated by authorized personnel.
- Semi-automatic mode: The arms are unlocked and can be rotated freely, but they will lock automatically after a certain period of time.
The ET-2000 is also available with a variety of options, including:
- Card reader: Allows authorized personnel to enter by swiping their card.
- Push button: Allows authorized personnel to enter by pressing a button.
- Biometric reader: Allows authorized personnel to enter by scanning their fingerprint or other biometric identifier.
The ET-2000 is a reliable and easy-to-use turnstile that is ideal for a variety of applications. It is a cost-effective solution for controlling pedestrian traffic and preventing unauthorized access.
